Water Heater Installation Kit
The heater is the thing you shopped for. These are the four parts the inspector, the warranty and the ceiling below actually care about.
Heat & Tap earns a commission on qualifying purchases made through the Amazon links on this page, at no extra cost to you. Commission does not decide what we recommend or how we rank it. Full disclosure.
For a standard 50-gallon replacement, buy four parts. An Amtrol Therm-X-Trol ST-12 expansion tank (4.4 gallon volume, 3.2 gallon acceptance, 11 in x 15 in) if the house is on a closed system. A Camco 20841 22-inch aluminium drain pan. A HoldRite QS-50 strap kit in a seismic jurisdiction — it carries California DSA approval #97-010. And a Honeywell AM-1 mixing valve if you want to store hot and deliver safe.
Nobody sells a genuine, complete water heater installation kit, because the right contents depend on your plumbing, your jurisdiction and where the tank sits. What the big-box "installation kit" boxes contain is usually two flexible connectors and a pair of dielectric unions — the easy parts. These are the four that get missed, and three of the four are code items somewhere in the country.
The four parts, side by side
| Part | Key specification | Why it is on the list |
|---|---|---|
| Amtrol Therm-X-Trol ST-12 | 4.4 gal volume, 3.2 gal acceptance, 11 in dia x 15 in H, 3/4 in NPTM, 150 psig max, 50 psig factory pre-charge | IPC 607.3 requires thermal expansion control on a closed system, and says the relief valve may not do the job |
| Camco 20841 aluminium pan | 22 in inside diameter, 2-1/4 in deep, PVC drain fitting | A 50-gallon tank will eventually leak; the pan decides whether that is a mop or a ceiling |
| HoldRite QS-50 Quick Strap kit | Up to 80 gal, 24 gauge galvanised steel, 38 in straps, 4 straps + 4 lag bolts + 4 J-clips, California DSA approval #97-010 | Seismic restraint is mandatory in California and several other jurisdictions, and the approval number goes on the permit |
| Honeywell AM-1 (AM101) mixing valve | 3/4 in lead-free brass, 150 psi, 212°F, adjustable 70 - 145°F depending on variant | Lets you store at 140°F for bacteria control and deliver at a safe tap temperature |
Quick picks
Tap any row to read the full assessment below, or go straight to Amazon from the right-hand column. We earn a commission on qualifying purchases at no extra cost to you.
| # | Product | Best for | Price |
|---|---|---|---|
| 1 |  Amtrol Therm-X-Trol ST-12The size most 50-gallon installs actually need: 4.4 gallons of volume and 3.2 gallons of acceptance, which is what Amtrol's chart calls for at 60 psi static pressure. | 50 gallon tanks at normal pressure | Check price on Amazon No live price feed on this site, so we show none. #ad |
| 2 |  Camco 20841 aluminum pan, 22 inThe 22-inch aluminum pan: the right size under a standard 50-gallon tank, which is itself usually 22 inches in diameter. | 50 gallon tanks | Check price on Amazon No live price feed on this site, so we show none. #ad |
| 3 |  HoldRite QS-50 Quick Strap kitThe strap kit inspectors recognize: 24-gauge galvanized steel for tanks up to 80 gallons, with California Division of the State Architect approval number 97-010. | Seismic zones, code compliance | Check price on Amazon No live price feed on this site, so we show none. #ad |
| 4 | Honeywell AM-1 (AM101) mixing valveThe thermostatic mixing valve that lets you store water at 140°F for bacteria control and still deliver a safe temperature at the tap — adjustable from 70 to 145°F depending on variant. | Storing hot, delivering safe | Check price on Amazon No live price feed on this site, so we show none. #ad |
The four parts in full
Pick 1 — 50 gallon tanks at normal pressure
Amtrol Therm-X-Trol ST-12
The size most 50-gallon installs actually need: 4.4 gallons of volume and 3.2 gallons of acceptance, which is what Amtrol's chart calls for at 60 psi static pressure.
| Tank volume | 4.4 gallons |
|---|---|
| Maximum acceptance volume | 3.2 gallons |
| Diameter | 11 in |
| Height | 15 in |
| System connection | 3/4 in NPTM |
| Maximum working pressure | 150 psig |
| Maximum operating temperature | 200°F |
| Factory pre-charge | 50 psig |
What is good
- 3.2 gallons of acceptance covers 50-gallon heaters at the static pressures most municipal supplies actually run
- Same 3/4 in NPTM connection and 150 psig rating as the ST-5
- Headroom means a slightly wrong pre-charge still works
- The size a plumber would fit by default
What is not
- 11 inches across and 15 inches tall needs real clearance above the heater
- Too heavy to hang unsupported from a horizontal tee
- Overkill for a 30- or 40-gallon tank on low pressure
Skip it if: Skip it if there is under 16 inches of clear space above your cold inlet. People buy the ST-12, find it will not fit, and then install it unsupported — which is how a tee cracks a year later.
No live price feed on this site, so we show none. #ad
Specifications above from Amtrol ST-12 sizing chart sheet (PDF); Amtrol Therm-X-Trol brochure, September 2025 (PDF). We have not tested this unit ourselves.
Pick 2 — 50 gallon tanks
Camco 20841 aluminum pan, 22 in
The 22-inch aluminum pan: the right size under a standard 50-gallon tank, which is itself usually 22 inches in diameter.
| Inside diameter | 22 in |
|---|---|
| Depth | 2.25 in |
| Material | Aluminum |
| Drain fitting | PVC |
What is good
- Matches the 22-inch diameter of the common 50-gallon tank with room for the fitting
- Aluminum construction
- Standard PVC drain connection
- Fits the alcove a 50-gallon tank already occupies
What is not
- A 22 in pan under a 22 in tank is a tight fit — check the drain boss clears
- 2.25 in depth
- Requires a gravity drain path
Skip it if: Skip it for a heat pump water heater. Those are usually wider than a resistance tank of the same capacity and also produce condensate continuously, which means a larger pan and a committed drain, not a shallow pan.
No live price feed on this site, so we show none. #ad
Specifications above from Pacific Plumbing listing, Camco 20841; HD Supply listing, Camco 22 in ID pan. We have not tested this unit ourselves.
Pick 3 — Seismic zones, code compliance
HoldRite QS-50 Quick Strap kit
The strap kit inspectors recognize: 24-gauge galvanized steel for tanks up to 80 gallons, with California Division of the State Architect approval number 97-010.
| Capacity | Water heaters up to 80 US gallons |
|---|---|
| Material | 24 gauge cold-rolled steel, galvanized |
| Strap length | 38 in |
| Kit contents | 4 straps, 4 lag bolts, 4 J-clips, 2 x 3/8 in carriage bolts, 2 x 3/8 in hex nuts |
| Approval | California DSA approval #97-010 |
What is good
- Named approval number is what an inspector in a seismic jurisdiction wants to see
- Complete kit: nothing to source separately at the hardware store
- Covers every residential tank size up to 80 gallons
- Galvanized steel will not rot off the wall in a damp garage
What is not
- Lag bolts need real studs or blocking, not drywall anchors
- Steel straps are harder to route around a tight alcove than a soft belt
- Over-tightening a steel strap can dent a tank jacket
Skip it if: Skip the rigid steel kit if the tank sits in a corner you cannot reach around. The soft-belt version exists for exactly that install, and a strap you cannot tension properly is decoration.
No live price feed on this site, so we show none. #ad
Specifications above from Supply House listing, HoldRite QS-50 galvanized strap; RWC BIM data, QS-50 water heater restraint. We have not tested this unit ourselves.
Pick 4 — Storing hot, delivering safe
Honeywell AM-1 (AM101) mixing valve
The thermostatic mixing valve that lets you store water at 140°F for bacteria control and still deliver a safe temperature at the tap — adjustable from 70 to 145°F depending on variant.
| Size | 3/4 in |
|---|---|
| Body | Brass, lead free |
| Pressure rating | 150 psi |
| Temperature rating | 212°F |
| Adjustable range | 70 - 145°F (variant dependent; 70 - 120°F and 70 - 180°F variants exist) |
| Connections | NPT, union CPVC, union press or PEX depending on variant |
What is good
- Lets you raise the tank set point for Legionella control without scalding anyone
- Also increases usable hot water: hotter storage mixed down goes further
- Multiple connection styles so it suits copper, CPVC, PEX or press
- Anti-scald and anti-chill in one device
What is not
- Several variants share the AM101 prefix with different temperature ranges — order the right one
- It is one more device on the hot outlet that can fail closed
- Needs a union or isolation to be serviceable
Skip it if: Skip it if you are not going to raise the tank temperature. Fitted to a tank set at 120°F it does almost nothing, and it adds a restriction and a failure point for no benefit.
No live price feed on this site, so we show none. #ad
Specifications above from First Supply listing, Honeywell AM101-UCPVC-1LF/U; Granite Group listing, AM101-UP-1LF/U, 70-145F. We have not tested this unit ourselves.
Which of these you actually need
- Expansion tank — only on a closed system. If cold water reaches the heater through a check valve, pressure-reducing valve or backflow preventer, you need one. Most modern houses have a PRV. Expansion tank code requirements has the code text, and expansion tank sizing explains why static pressure, not tank gallons, drives the size.
- Drain pan — any time there is something below worth protecting. Buy it by inside diameter: 20 inches for most 30 and 40 gallon tanks, 22 inches for a 50, 26 inches for an 80 or a heat pump model. The drain fitting has to go somewhere, or the pan just holds two gallons and overflows.
- Seismic straps — wherever the jurisdiction says so. Two straps, upper and lower third, four inches clear of the controls, mechanically fixed to studs. Water heater earthquake strap requirements quotes the statute.
- Mixing valve — if you store above 120°F. Storing at 140°F suppresses bacterial growth; delivering at 140°F scalds. The valve is how you have both.
What else goes on the van
- Flexible connectors and dielectric unions. Genuinely useful, genuinely cheap, and usually what is in the box labelled installation kit.
- A T&P discharge pipe run to within a few inches of the floor or outside, in a material rated for the temperature. Never capped, never valved.
- Pipe dope or PTFE tape rated for potable water.
- A leak detector. The pan tells you nothing; a sensor in the pan tells you at 2am. Best water heater leak detectors.
- A new anode rod, if the heater is going somewhere awkward to service later. Water heater anode rods.
Buy by job type
| Job | Buy | Skip |
|---|---|---|
| 50-gallon tank, basement, closed system | ST-12 expansion tank + 22 in pan | Straps, unless your jurisdiction requires them |
| Tank in an upstairs closet | Pan + leak detector + expansion tank | Nothing — this is the install where everything earns its place |
| California or another seismic jurisdiction | HoldRite QS-50 strap kit | Nothing; the approval number goes on the permit |
| Household with young children or elderly residents | Honeywell AM-1 mixing valve | Nothing — store hot, deliver safe |
| 80-gallon or heat pump model | 26 in pan instead of 22 | The 22 in pan; it will not fit |
| Open system, slab floor, floor drain alongside | Pan only | The expansion tank, if the system is genuinely open |
If you are doing the work yourself rather than buying parts for a plumber, read can I replace my own water heater? first — the permit question decides more of this than the parts list does.
